適用範圍Application:
廣泛運用於服装、箱包、鞋类等大裁片需要烫唛头、热转印商标的工艺。
Widely used in the clothes, bags, shoes hot stamping of label
產品特點Features::
1、 设备自动放唛头,无需定位板定位,对位精度高。Automatic put the label on the right place, no need locking plate location, high alignment accuracy.
2、 溫度、壓力、轉印時間均可根據客戶實際要求設置,可以根據溫度的偏差進行糾正,可根據客戶要求設置溫度異常、氣壓壓力異常報警,保證產品品質。单片烫唛头时间约5~8S,效率快。Temperature, press and transfer time can be adjusted according to the effect requirement, with pressure abnormal alarm, ensure the product quality. the transfer time per piece is 5S to 8S.
3、 带自动固定材料机构,取料、放料方便,提高操作效率。Automatic fixing material device, feeding and emptying material easily, increase operational efficiency.
4、 根据客户产品要求,一人可同时操作2~3台设备。One worker can operate 2 or 3 sets machine at the same time.
型號Model No. | 機台尺寸(mm)Machine measure | 出口木箱尺寸(mm) Wood case measure | 淨重/毛重kg N.W/ G.W (kg) | 產能Capacity | 模具尺寸 Max mould size |
FLD-590H | 950*750*1700 | 1000*800*1840 | 230/250 | 5~8S/次 5~8S/time
| 100*100mm |
電源電壓Voltage | 氣源氣壓Air pressure | 功率Power | 溫度可調範圍Heat transfer temperature | ||
220V | 4.5~6kpa | 2kw | 30~250℃ |
